Product highlights of New Model E7G HOWO tractor truck
2.1 Lighter Weight and Higher Benefit
HOWO E7G lightweight tractor truck adopts platform and modular design, while designing to reduce own weight, the tractor truck also adopts new materials such as: aluminum alloy transmission (optional), single-layer frame, aluminum alloy fuel tank, lightweight fifth wheel, few pcs of leaf spring and vacuum tires etc. to reduces the overall weight of the vehicle, the trucks carry more cargo under standard loading conditions.
(Change from HW series steel shell transmission to aluminum shell transmission，reduce weight about 80 kgs)
HOWO E7G380 lightweight Tractor Head is optimized by MAN technology for power matching, Combining the characteristics of domestic and foreign road logistics transportation with on-board logistics and high-speed transportation. The SINOTRUK group develops the new generation of systematic HOWO E7G highway fuel-saving tractors. The tractor trucks can reduce fuel consumption by 10-13%, which is equivalent to saving more than USD 6,000 for transporters each year.
1. Standard SINOTRUK HOWO 10 or 12 liter high-power engines, low speed and large torque, economic speed range 1100-1600 rpm
(Other brands of engines generally 1200-1500rpm), more fuel efficient
2. The HOWO tractor truck is optional to install 12-speed and low-speed ratio gearbox, economic and wide speed range, high engine load rate, and more fuel-efficient truck
3.The E7G HOWO tractor truck use German Mercedes-Benz technical cab, which has a smaller wind resistance coefficient (up to 0.49).
It is useful to reduce vehicle high-speed driving resistance and reduces fuel consumption by more than 5%.
The tractor trucks installed vacuum tires. Rolling resistance is smaller, which saving fuel up to 2-3 liters per 100 kilometers
4. The HOWO tractor trucks use large-capacity air filter, which have large air intake, low air intake resistance, sufficient combustion, good power and higher fuel efficient
1. The HOWO tractor truck is fully matched with a multi-speed over speed gearbox (also known as a fast gearbox) and a low speed ratio rear axle (also called a fast axle).
2. When the engine on 1500 rpm, the economic speed of HOWO truck can reach about 90 km/h, which meets the needs of most road transport.
3. When the vehicle is fully matched with the fast gearbox and the fast axle, both the maximum speed and the economic speed of the vehicle are increased by more than 20% compared with the matching direct gear box.
(Side View of E7G380 Tractor Truck)
1. Driving Cabin
The HOWO trucks use German Mercedes-Benz technical cab, all-steel body. Thickness of Cab steel is 20% thicker than other brand trucks.(The HOWO E7G Tuck is 1mm,other brand is 0.8mm
The HOWO E7G tractor trucks have advanced structure, light weight, high reliability and good safety. The cab welding and production line of HOWO trucks is finished by 8 robots automatically from ABB company.
The HOWO trucks use high-quality sixth-generation cathodic electrophoretic paint, and the middle and top coats are automatically painted by 6 robots which effectively ensures the appearance quality of the body. The anti-rust and aging resistance of the truck body Increased by more than 2 times compared with the traditional electrophoretic coating. The residual value of truck is higher.
The HOWO tractor truck use ergonomic design, four-point suspension, around type instruments and silent design. Having good comfort, low driving fatigue and improve transportation efficiency better.
Each safety performance indicators of HOWO tractor trucks fully comply with European ECE R29 regulations, and the safety performance has been comprehensively improved.
2. Brake safety
Equipped with German VOSS braking system and original WABCO ABS system, widening brake shoes, safe and effective braking;
The selection of MAN technology EVB exhaust brake and hydraulic retarder can improve the braking safety of downhill slopes. The braking system meets the requirements of relevant European regulations
3. Cooling system
The cooling system optimized by MAN technology. The HOWO tractor truck uses a widened water tank and a C-type windshield. The cooling capacity of the engine is further improved. The vehicle fully meets the operational needs of plateaus, high altitudes, high heat and complex mountain roads.
Engine: China Sinotruk HOWO 10 or 12 liters high-power engine, low speed and high torque, strong starting, climbing and acceleration capabilities; By Technology improvement reduces fuel consumption more than 8% compared with similar engines; standard EVB, high-speed driving control and safer and better Braking efficiency.
Transmission: The HOWO E7G Tractor truck adopts multi-gear high-torque transmission with large reserve torque, high reliability and low failure rate.
Clutch: HOWO tractor trucks use pull-type Φ430 diaphragm clutch, have lighter weight, larger clamping force, strong heat dissipation ability and longer lifespan.
Drive axle: HOWO trucks adopt 457 single-stage reduction Axle, long term market-tested shows they are mature and reliable technology
Electrical instrument: the tractor truck use stepper motor instrument, the technology is reliable, durable, low failure rate, more convenient on inspection and maintenance.
1. The warranty period of the HOWO E7G tractor trucks is extended to 18 months or 150,000 km, which is 6 months or 30,000 kilometers longer than the industry average. Each unit tractor truck can save USD 2,000-4,000 per year
2. Adopt HOWO Universal large assembly, sufficient spare parts in stock, low use cost
3. The structure of HOWO tractor truck is scientific and reasonable, and the maintenance is more convenient:
①The HOWO truck cab flip angle can reach 55 °. After the cab is flipped, the engine, water tank, intercooler and other components can be directly suspended for easy after-sales maintenance.
②Opening the front panel of truck, you can check the oil level, add oil, brake fluid, windshield washer fluid, and clean the air conditioning filter element, etc. Convenient and practical
(Easy maintain and larger cab flip angle on HOWO E7G TRACTOR TRUCK)
1. Contact with your China HOWO truck suppliers.
2. Tell to your suppliers if you have special request on the trucks, like add extra fuel tank, pump and PTO etc.
3. The suppliers recommend and quote the suitable truck model for you
4. Doing business negotiate with your suppliers in price, order quantities, delivery time, and payment term and sign a proforma invoice/ Sales contact
5. You take the proforma Invoice/ Sales contract to local international bank and paid on T/T（telegraphic transfer）through bank.
6. The supplier start production after received your deposit, they will send you the videos and photos during production
7. After finished production, the supplier will invite you come to China to inspect the truck. If you are busy and no time to visit, we will send you the finished photo and test video of truck.
8. After you confirmed the trucks are okay, we will start the delivery.
9. You need to do the custom clearance after received the trucks.
